| Type Number | Main Difference |
| M130DPCSx | UART |
| M130GPCSx | UART M1 instruction integration is high |
>>Features
- M130GPCSx serials M1 instruction integration is high and the user's operation is simpler
- Frequency: 13.56MHz
- Embeded NXP transceive IC as RF base sation
- Compliant with the standard of ISO14443 TYPE A/Mifare
- Completed operation command set,and user needn't to care for the complex control ,can implement all the operation for the IC cards.
- Integrated with antenna
- Dimension include antenna:63X35mm
- Communication interface:UART
- Embeded with watchdog
- Source code samples for C51
- Software can be customized according to the customer requirements
- Application for the fields of transport, access door control, smart meters, login in or login out checker, industrial,etc
>>Optional antennas(None)
| Type Number | Dimension | Operation Distance |
>>Electrical Characteristics
- Frequency: 13.56MHz
- Operation distance:40~60mm(Testing base on standard S50)
- Power Supply:DC3.3V/DC5V
- Current:Standard modules:3.3V/35mA(High Power Modules:3.3V/90mA)
- Temperature range:-10℃～+70℃
- Demision:63X35mm
- Pin to pin distance:2.54mm
>>Main Difference
| Type Number | Main Difference | Support Tags |
| M130DPCSV3 | UART(8bits), DC3.3V, Low Power | Mifare S50,S70,FM11RF08,FM1208,FM1204, Desfire, Ultralight, Ntag and compatible cards |
| M130DPCSV3B | UART(8bits), DC3.3V, High Power | Mifare S50,S70,FM11RF08,FM1208,FM1204, Desfire, Ultralight, Ntag and compatible cards |
| M130DPCSV5 | UART(8bits), DC5V, Low Power | Mifare S50,S70,FM11RF08,FM1208,FM1204, Desfire, Ultralight, Ntag and compatible cards |
| M130DPCSV5B | UART(8bits), DC5V, High Power | Mifare S50,S70,FM11RF08,FM1208,FM1204, Desfire, Ultralight, Ntag and compatible cards |
| M130GPCSV3 | UART(8bits), DC3.3V, Low Power | Mifare S50,S70,FM11RF08,Ultralight, Ntag and compatible cards |
| M130GPCSV3B | UART(8bits), DC3.3V, High Power | Mifare S50,S70,FM11RF08,Ultralight, Ntag and compatible cards |
| M130GPCSV5 | UART(8bits), DC5V, Low Power | Mifare S50,S70,FM11RF08,Ultralight, Ntag and compatible cards |
| M130GPCSV5B | UART(8bits), DC5V, High Power | Mifare S50,S70,FM11RF08,Ultralight, Ntag and compatible cards |
